Not sure if this is the standard behavior, but the current client version my systems are using is 5.00.8634.1814. However the version that is installing during imaging is not the latest version. Is there a way to resolve this during imaging, or do I just wait until the client upgrades itself? Thanks Jesse -
I've got a new installation of SCCM 2012 that is going mostly well. This was a clean install, but I believe this environment may have tried SCCM 2007 at some point in the past, though unsuccessfully. I have a couple clients that are failing installation. They are all Windows XP. Here is a snippit of the ccmsetup.log. Current AD site of machine is HQ Local Machine is joined to an AD domain Current AD forest name is domain.local, domain name is domain.local DHCP entry points already initialized. Begin checking Alternate Network Configuration Finished checking Alternate Network Configuration Adapter {5A85755B-F909-4D9C-A46E-0BE51D804DD6} is DHCP enabled. Checking quarantine status. Sending message body '<ContentLocationRequest SchemaVersion="1.00"> <AssignedSite SiteCode="AHI"/> <ClientPackage/> <ClientLocationInfo LocationType="SMSPACKAGE" DistributeOnDemand="0" UseProtected="0" AllowCaching="0" BranchDPFlags="0" AllowHTTP="1" AllowSMB="0" AllowMulticast="0" UseInternetDP="0"> <ADSite Name="HQ"/> <Forest Name="domain.local"/> <Domain Name="domain.local"/> <IPAddresses> <IPAddress SubnetAddress="10.0.1.0" Address="10.0.1.77"/> </IPAddresses> </ClientLocationInfo> </ContentLocationRequest> ' Sending message header '<Msg SchemaVersion="1.1"><ID>{81019CDF-2B74-4089-93D1-A4C32BCA8C5E}</ID><SourceHost>CLIENTXP</SourceHost><TargetAddress>mp:[http]MP_LocationManager</TargetAddress><ReplyTo>direct:CLIENTXP:LS_ReplyLocations</ReplyTo><Priority>3</Priority><Timeout>600</Timeout><ReqVersion>5931</ReqVersion><TargetHost>https://SCCMserver.domain.local</TargetHost><TargetEndpoint>MP_LocationManager</TargetEndpoint><ReplyMode>Sync</ReplyMode><Protocol>http</Protocol><SentTime>2012-10-12T15:06:44Z</SentTime><Body Type="ByteRange" Offset="0" Length="1082"/><Hooks><Hook3 Name="zlib-compress"/></Hooks><Payload Type="inline"/></Msg>' CCM_POST 'https://SCCMserver.domain.local/ccm_system/request' Begin searching client certificates based on Certificate Issuers Completed searching client certificates based on Certificate Issuers Begin to select client certificate The 'Certificate Selection Criteria' was not specified, counting number of certificates present in 'MY' store of 'Local Computer'. 1 certificate(s) found in the 'MY' certificate store. Only one certificate present in the certificate store. Begin validation of Certificate [Thumbprint 177CC907017F1F85AE0630C211E747D8C2B4352F] issued to 'clientXP.domain.local' Certificate [Thumbprint 177CC907017F1F85AE0630C211E747D8C2B4352F] issued to 'clientXP.domain.local' doesn't have private key or caller doesn't have access to private key. Completed validation of Certificate [Thumbprint 177CC907017F1F85AE0630C211E747D8C2B4352F] issued to 'clientXP.domain.local' GetSSLCertificateContext failed with error 0x87d00283 GetHttpRequestObjects failed for verb: 'CCM_POST', url: 'https://SCCMserver.domain.local/ccm_system/request' GetDPLocations failed with error 0x87d00283 Failed to find DP locations with error 0x87d00283, status code 200. Check next MP. Only one MP https://SCCMserver.domain.local is specified. Use it. Have already tried all MPs. Couldn't find DP locations. GET 'https://SCCMserver.domain.local/CCM_Client/ccmsetup.cab' Begin searching client certificates based on Certificate Issuers Completed searching client certificates based on Certificate Issuers Begin to select client certificate The 'Certificate Selection Criteria' was not specified, counting number of certificates present in 'MY' store of 'Local Computer'. 1 certificate(s) found in the 'MY' certificate store. Only one certificate present in the certificate store. Begin validation of Certificate [Thumbprint 177CC907017F1F85AE0630C211E747D8C2B4352F] issued to 'clientXP.domain.local' Certificate [Thumbprint 177CC907017F1F85AE0630C211E747D8C2B4352F] issued to 'clientXP.domain.local' doesn't have private key or caller doesn't have access to private key. Completed validation of Certificate [Thumbprint 177CC907017F1F85AE0630C211E747D8C2B4352F] issued to 'clientXP.domain.local' GetSSLCertificateContext failed with error 0x87d00283 GetHttpRequestObjects failed for verb: 'GET', url: 'https://SCCMserver.domain.local/CCM_Client/ccmsetup.cab' DownloadFileByWinHTTP failed with error 0x87d00283 CcmSetup failed with error code 0x87d00283 This should not be a boundary issue. I have defined all of my subnets as boundaries and joined them to a boundary group. This client is on the same subnet as many other clients that are working fine. The certificate is issued and the root CA is trusted. I have removed and rejoined this client to the domain. I have run winmgmt /resetrepository on this client. I looked up the 0x87d00283 with net helpmsg and it returns: This doesn't make any sense to me. My forest and domain function level is Windows 2008. These particular clients are Windows XP Professional SP3. I have many other WinXP SP3 clients working fine. I've pretty well run out of ideas and would welcome any discussion on the subject that might help me in any way. Thanks for listening!
-
Good morning, I have tried installing the client through the client push method and by running the setup file locally on the PC, but my clients never return a hardware or software scan. They return Heartbeat DDR and policy request dates, but even when manually prompting them to do hardware/software scans from the client it does not work. I am running SCCM 2012 Eval version. When I run Hardware inventory from the client this is the output from InventoryAgent.log: There are many errors, but I am not sure where to start or what they mean... --- Inventory: *********************** Start of message processing. *********************** InventoryAgent 12/15/2014 8:14:06 AM 12860 (0x323C) Inventory: Message type is InventoryAction InventoryAgent 12/15/2014 8:14:06 AM 12860 (0x323C) Inventory: Temp directory = C:\WINDOWS\CCM\Inventory\Temp\ InventoryAgent 12/15/2014 8:14:06 AM 12860 (0x323C) Inventory: Clearing old collected files. InventoryAgent 12/15/2014 8:14:06 AM 12860 (0x323C) Inventory: Opening store for action {00000000-0000-0000-0000-000000000001} ... InventoryAgent 12/15/2014 8:14:06 AM 12860 (0x323C) Inventory: Action=Hardware, ReportType=Delta, MajorVersion=2, MinorVersion=2 InventoryAgent 12/15/2014 8:14:31 AM 12860 (0x323C) Inventory: Initialization completed in 24.610 seconds InventoryAgent 12/15/2014 8:14:31 AM 12860 (0x323C) Collection: Namespace = \\.\root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, Version FROM Win32_WindowsUpdateAgentVersion; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:31 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Availability, Caption, Description, DeviceID, Drive, Manufacturer, MediaType, Name, SCSITargetId, SystemName, VolumeName FROM Win32_CDROMDrive; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:31 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\CCM\powermanagementagent; Query = SELECT __CLASS, __PATH, __RELPATH, ApmPresent, BatteriesAreShortTerm, FullWake, LidPresent, MinDeviceWakeState, PreferredPMProfile, ProcessorThrottle, RtcWake, SystemBatteriesPresent, SystemS1, SystemS2, SystemS3, SystemS4, SystemS5, UpsPresent, VideoDimPresent FROM CCM_PwrMgmtSystemPowerCapabilities; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:31 AM 2784 (0x0AE0) Collection: Namespace = \\localhost\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, DisplayName, InstallDate, ProdID, Publisher, Version FROM Win32Reg_AddRemovePrograms; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:31 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Availability, Capabilities, DeviceID, Name, Status FROM Win32_ParallelPort; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:32 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, AdapterCompatibility, AdapterDACType, AdapterRAM, CurrentBitsPerPixel, CurrentHorizontalResolution, CurrentNumberOfColumns, CurrentNumberOfRows, CurrentRefreshRate, CurrentScanMode, CurrentVerticalResolution, Description, DeviceID, DriverDate, DriverVersion, InstalledDisplayDrivers, Name, NumberOfColorPlanes, SpecificationVersion, VideoMode, VideoModeDescription, VideoProcessor FROM Win32_VideoController; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:32 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, DefaultIPGateway, DHCPEnabled, DHCPServer, DNSDomain, DNSHostName, Index, IPAddress, IPEnabled, IPSubnet, MACAddress, ServiceName FROM Win32_NetworkAdapterConfiguration; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:32 AM 2784 (0x0AE0) Collection: Namespace = root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, FullName, InstallState, UserAccountName, UserSecurityId FROM SMS_Windows8ApplicationUserInfo; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:32 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Caption, ClassGuid, ConfigManagerErrorCode, ConfigManagerUserConfig, CreationClassName, Description, DeviceID, Manufacturer, Name, PNPDeviceID, Service, Status, SystemCreationClassName, SystemName FROM Win32_USBDevice; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:36 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Description, Manufacturer, Name, Status FROM Win32_NetworkClient; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:36 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, CompatibleIDs, DeviceID, HardwareIDs, IsPnP, Name FROM CCM_SystemDevices; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:36 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, SecurityLogStartDate, TopConsoleUser, TotalConsoleTime, TotalConsoleUsers, TotalSecurityLogTime FROM SMS_SystemConsoleUsage; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:38 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, ID, Name, ParentID FROM Win32_ServerFeature; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:40 AM 2784 (0x0AE0) Collection: Class "Win32_ServerFeature" does not exist. InventoryAgent 12/15/2014 8:14:40 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Name, TotalPageFileSpace, TotalPhysicalMemory, TotalVirtualMemory FROM CCM_LogicalMemoryConfiguration; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:40 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, DisplayName, Name, PathName, ServiceType, StartMode, StartName, Status FROM Win32_Service; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:40 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, ApplicationID, Description, EvaluationEndDate, GracePeriodRemaining, ID, LicenseStatus, MachineURL, Name, OfflineInstallationId, PartialProductKey, ProcessorURL, ProductKeyID, ProductKeyURL, UseLicenseURL FROM SoftwareLicensingProduct; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:43 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\CCM\powermanagementagent; Query = SELECT __CLASS, __PATH, __RELPATH, Requester, RequesterInfo, RequesterType, RequestType, Time, UnknownRequester FROM CCM_PwrMgmtLastSuspendError; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:44 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, AdditionalProductCodes, CompanyName, ExplorerFileName, FileDescription, FilePropertiesHash, FileSize, FileVersion, FolderPath, LastUsedTime, LastUserName, msiDisplayName, msiPublisher, msiVersion, OriginalFileName, ProductCode, ProductLanguage, ProductName, ProductVersion, SoftwarePropertiesHash FROM CCM_RecentlyUsedApps; Timeout = 600 secs. InventoryAgent 12/15/2014 8:14:44 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\CCM\powermanagementagent; Query = SELECT __CLASS, __PATH, __RELPATH, Date, hr0_1, hr1_2, hr10_11, hr11_12, hr12_13, hr13_14, hr14_15, hr15_16, hr16_17, hr17_18, hr18_19, hr19_20, hr2_3, hr20_21, hr21_22, hr22_23, hr23_0, hr3_4, hr4_5, hr5_6, hr6_7, hr7_8, hr8_9, hr9_10, minutesTotal, TypeOfEvent FROM CCM_PwrMgmtActualDay; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:10 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, AMT, AMTApps, BiosVersion, BuildNumber, DeviceID, Flash, LegacyMode, Netstack, ProvisionMode, ProvisionState, RecoveryBuildNum, RecoveryVersion, Sku, TLSMode, VendorID, ZTCEnabled FROM SMS_AMTObject; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:10 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Availability, Description, DeviceID, MediaType, Name, Status FROM Win32_TapeDrive; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:10 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, AvailableLicenses, Description, IssuedLicenses, KeyPackId, KeyPackType, ProductType, ProductVersion, TotalLicenses FROM Win32_TSLicenseKeyPack; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:10 AM 2784 (0x0AE0) Collection: Class "Win32_TSLicenseKeyPack" does not exist. InventoryAgent 12/15/2014 8:15:10 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Access, Bootable, BootPartition, Description, DeviceID, Name, PrimaryPartition, Size, SystemName, Type FROM Win32_DiskPartition; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:10 AM 2784 (0x0AE0) Collection: Namespace = \\localhost\root\Microsoft\appvirt\client; Query = SELECT __CLASS, __PATH, __RELPATH, CachedLaunchSize, CachedPercentage, CachedSize, LaunchSize, Name, PackageGUID, TotalSize, Version, VersionGUID FROM Package; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:10 AM 2784 (0x0AE0) Failed to get IWbemService Ptr for \\localhost\root\Microsoft\appvirt\client Namespace: 8004100E InventoryAgent 12/15/2014 8:15:10 AM 2784 (0x0AE0) Failed to enumerate instances of Package: 8004100E InventoryAgent 12/15/2014 8:15:10 AM 2784 (0x0AE0) Collection: Namespace = root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, ApplicationName, Architecture, ConfigMgrManaged, DependencyApplicationNames, FamilyName, FullName, InstalledLocation, IsFramework, Publisher, PublisherId, Version FROM SMS_Windows8Application; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:10 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, ACSettingIndex, ACValue, DCSettingIndex, DCValue, GUID, Name, UnitSpecifier FROM SMS_PowerSettings; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:14 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Description, DeviceID, DisplayType, MonitorManufacturer, MonitorType, Name, PixelsPerXLogicalInch, PixelsPerYLogicalInch, ScreenHeight, ScreenWidth FROM Win32_DesktopMonitor; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:15 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Availability, Description, DeviceID, Manufacturer, Name, Status FROM Win32_IDEController; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:15 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, ConfigManagerErrorCode, DeviceID, ErrorDescription, LastErrorCode, Name, PNPDeviceID FROM Win32_PnpEntity; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:15 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, BootDevice, BuildNumber, Caption, CountryCode, CSDVersion, Description, InstallDate, LastBootUpTime, Locale, Manufacturer, Name, Organization, OSLanguage, ProductType, RegisteredUser, SystemDirectory, TotalSwapSpaceSize, TotalVirtualMemorySize, TotalVisibleMemorySize, Version, WindowsDirectory FROM Win32_OperatingSystem; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:17 AM 2784 (0x0AE0) Skipping Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, InstanceKey, PhysicalHostName, PhysicalHostNameFullyQualified FROM Win32Reg_SMSGuestVirtualMachine, we're running on a 64-bit platform and attempting to force enumerating 32-bit data. InventoryAgent 12/15/2014 8:15:17 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, Availability, Compressed, Description, DeviceID, DriveType, FileSystem, Name, Size, SystemName, VolumeName, VolumeSerialNumber FROM SMS_LogicalDisk; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:17 AM 2784 (0x0AE0) Collection: Namespace = \\localhost\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, DisplayName, InstallDate, ProdID, Publisher, Version FROM Win32Reg_AddRemovePrograms64; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:17 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, AdapterType, Description, DeviceID, MACAddress, Manufacturer, Name, ProductName, ServiceName, Status FROM Win32_NetworkAdapter; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:18 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Availability, Description, DeviceID, Name FROM Win32_USBController; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:18 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Availability, Description, DeviceID, InstallDate, Manufacturer, Name, PNPDeviceID, ProductName, Status FROM Win32_SoundDevice; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:18 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\ccm\ClientSDK; Query = SELECT __CLASS, __PATH, __RELPATH, AdminAllowOptout, EffectiveClientOptOut, IsClientOptOut FROM CCM_PowerManagementClientOptoutSetting; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:18 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\Nap; Query = SELECT __CLASS, __PATH, __RELPATH, description, fixupState, friendlyName, id, infoClsid, isBound, percentage, registrationDate, vendorName, version FROM NAP_SystemHealthAgent; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:18 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, LastConsoleUse, NumberOfConsoleLogons, SystemConsoleUser, TotalUserConsoleMinutes FROM SMS_SystemConsoleUser; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:18 AM 2784 (0x0AE0) Collection: Namespace = \\localhost\root\vm\VirtualServer; Query = SELECT __CLASS, __PATH, __RELPATH, Name FROM VirtualMachine; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:21 AM 2784 (0x0AE0) Failed to get IWbemService Ptr for \\localhost\root\vm\VirtualServer Namespace: 8004100E InventoryAgent 12/15/2014 8:15:21 AM 2784 (0x0AE0) Failed to enumerate instances of VirtualMachine: 8004100E InventoryAgent 12/15/2014 8:15:21 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, CertificateSelectionCriteria, CertificateStore, ClientAlwaysOnInternet, HttpsStateFlags, InstanceKey, InternetMPHostName, SelectFirstCertificate FROM Win32Reg_SMSAdvancedClientSSLConfiguration; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:21 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, AddressWidth, BrandID, CPUHash, CPUKey, DataWidth, DeviceID, Family, Is64Bit, IsHyperthreadCapable, IsMobile, IsTrustedExecutionCapable, IsVitualizationCapable, Manufacturer, MaxClockSpeed, Name, NormSpeed, NumberOfCores, NumberOfLogicalProcessors, PCache, ProcessorId, ProcessorType, Revision, SocketDesignation, Status, SystemName, Version FROM SMS_Processor; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:21 AM 2784 (0x0AE0) Collection: Namespace = root\ccm; Query = SELECT __CLASS, __PATH, __RELPATH, DisplayName, Name, Version FROM CCM_InstalledComponent; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:22 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, BankLabel, Capacity, Caption, CreationClassName, DataWidth, Description, DeviceLocator, FormFactor, HotSwappable, InstallDate, InterleaveDataDepth, InterleavePosition, Manufacturer, MemoryType, Model, Name, OtherIdentifyingInfo, PartNumber, PositionInRow, PoweredOn, Removable, Replaceable, SerialNumber, SKU, Speed, Status, Tag, TotalWidth, TypeDetail, Version FROM Win32_PhysicalMemory; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:23 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, HealthStatus, LocalPath, RoamingConfigured, RoamingPath, RoamingPreference, SID, Special, Status FROM Win32_UserProfile; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:23 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, BinFileVersion, BinProductVersion, Description, ExecutableName, FilePropertiesHash, FilePropertiesHashEx, FileSize, FileVersion, HasPatchAdded, InstalledFilePath, IsSystemFile, IsVitalFile, Language, Product, ProductCode, ProductVersion, Publisher FROM SMS_InstalledExecutable; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:23 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\Nap; Query = SELECT __CLASS, __PATH, __RELPATH, description, fixupURL, name, napEnabled, napProtocolVersion, systemIsolationState FROM NAP_Client; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:51 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, ChassisTypes, Manufacturer, Model, SerialNumber, SMBIOSAssetTag, Tag FROM Win32_SystemEnclosure; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:51 AM 2784 (0x0AE0) Collection: Namespace = \\localhost\root\Microsoft\appvirt\client; Query = SELECT __CLASS, __PATH, __RELPATH, LastLaunchOnSystem, Name, PackageGUID, Version FROM Application; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:51 AM 2784 (0x0AE0) Failed to get IWbemService Ptr for \\localhost\root\Microsoft\appvirt\client Namespace: 8004100E InventoryAgent 12/15/2014 8:15:51 AM 2784 (0x0AE0) Failed to enumerate instances of Application: 8004100E InventoryAgent 12/15/2014 8:15:51 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\CCM\powermanagementagent; Query = SELECT __CLASS, __PATH, __RELPATH, minutesComputerActive, minutesComputerOn, minutesComputerShutdown, minutesComputerSleep, minutesMonitorOn, minutesTotal, MonthStart FROM CCM_PwrMgmtMonth; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:51 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, AnswerMode, DeviceID, DeviceType, Index, MaxBaudRateToPhone, MaxBaudRateToSerialPort, Model, Name, Properties, Status, StringFormat, SystemName, VoiceSwitchFeature FROM Win32_POTSModem; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:52 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, ARPDisplayName, ChannelCode, ChannelID, CM_DSLID, EvidenceSource, InstallDate, InstallDirectoryValidation, InstalledLocation, InstallSource, InstallType, Language, LocalPackage, MPC, OsComponent, PackageCode, ProductID, ProductName, ProductVersion, Publisher, RegisteredUser, ServicePack, SoftwareCode, SoftwarePropertiesHash, SoftwarePropertiesHashEx, UninstallString, UpgradeCode, VersionMajor, VersionMinor FROM SMS_InstalledSoftware; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:52 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\CCM\policy\machine\actualconfig; Query = SELECT __CLASS, __PATH, __RELPATH, NonPeakPowerPlanName, PeakPowerPlanName, PowerConfigID, WakeUpTimeHoursMin FROM CCM_PowerConfig; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Description, DeviceID, PrimaryBusType, RevisionNumber, SecondaryBusType, Status, StatusInfo, SystemName FROM Win32_MotherboardDevice; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Availability, Description, DeviceID, DriverName, HardwareVersion, Index, Manufacturer, Name, Status FROM Win32_SCSIController; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Namespace = root\SmsDm; Query = SELECT __CLASS, __PATH, __RELPATH, DeviceOEMInfo, DeviceType, InstalledClientID, InstalledClientServer, InstalledClientVersion, LastSyncTime, OS_AdditionalInfo, OS_Build, OS_Major, OS_Minor, OS_Platform, ProcessorArchitecture, ProcessorLevel, ProcessorRevision FROM SMS_ActiveSyncConnectedDevice; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Class "SMS_ActiveSyncConnectedDevice" does not exist. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, BuildNumber, Description, Manufacturer, Name, ReleaseDate, SerialNumber, SMBIOSBIOSVersion, SoftwareElementID, SoftwareElementState, TargetOperatingSystem, Version FROM Win32_BIOS; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Attributes, Availability, AveragePagesPerMinute, Capabilities, CapabilityDescriptions, Caption, ConfigManagerErrorCode, ConfigManagerUserConfig, DefaultPriority, Description, DetectedErrorState, DeviceID, DriverName, ErrorCleared, ErrorDescription, HorizontalResolution, InstallDate, JobCountSinceLastReset, LanguagesSupported, LastErrorCode, Location, Name, PaperSizesSupported, PNPDeviceID, PortName, PowerManagementCapabilities, PowerManagementSupported, PrinterPaperNames, PrinterState, PrinterStatus, PrintJobDataType, PrintProcessor, SeparatorFile, ServerName, ShareName, SpoolEnabled, StartTime, Status, StatusInfo, SystemName, TimeOfLastReset, UntilTime, VerticalResolution FROM Win32_Printer; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, CurrentTimeZone, Description, Domain, DomainRole, Manufacturer, Model, Name, NumberOfProcessors, Roles, Status, SystemType, UserName FROM Win32_ComputerSystem; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, ExpirationDate, IssueDate, KeyPackId, LicenseId, LicenseStatus, sHardwareId, sIssuedToComputer, sIssuedToUser FROM Win32_TSIssuedLicense; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Class "Win32_TSIssuedLicense" does not exist. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, Availability, Caption, Description, DeviceID, Index, InterfaceType, Manufacturer, MediaType, Model, Name, Partitions, PNPDeviceID, SCSIBus, SCSILogicalUnit, SCSIPort, SCSITargetId, Size, SystemName FROM Win32_DiskDrive; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Namespace = root\SmsDm; Query = SELECT __CLASS, __PATH, __RELPATH, LastSyncTime, MajorVersion, MinorVersion FROM SMS_ActiveSyncService; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Class "SMS_ActiveSyncService" does not exist. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\ccm\invagt; Query = SELECT __CLASS, __PATH, __RELPATH, Name, SMSID, Domain, SystemRole, SystemType, LocalDateTime FROM CCM_System; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, ClientMachineID, IsKeyManagementServiceMachine, KeyManagementServiceCurrentCount, KeyManagementServiceMachine, KeyManagementServiceProductKeyID, PolicyCacheRefreshRequired, RequiredClientCount, Version, VLActivationInterval, VLRenewalInterval FROM SoftwareLicensingService; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:54 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2\sms; Query = SELECT __CLASS, __PATH, __RELPATH, FolderName, HealthStatus, OfflineAccessEnabled, Redirected, SID FROM SMS_FolderRedirectionHealth; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:55 AM 2784 (0x0AE0) Collection: Namespace = \\.\root\cimv2; Query = SELECT __CLASS, __PATH, __RELPATH, InstanceKey, PhysicalHostName, PhysicalHostNameFullyQualified FROM Win32Reg_SMSGuestVirtualMachine64; Timeout = 600 secs. InventoryAgent 12/15/2014 8:15:56 AM 2784 (0x0AE0) Update cached IWbemService pointer to namespace: \\.\root\cimv2 InventoryAgent 12/15/2014 8:15:56 AM 2784 (0x0AE0) Collection: 57/66 inventory data items successfully inventoried. InventoryAgent 12/15/2014 8:15:56 AM 2784 (0x0AE0) Inventory: Collection Task completed in 85.000 seconds InventoryAgent 12/15/2014 8:15:56 AM 2784 (0x0AE0) Inventory: 9 Collection Task(s) failed. InventoryAgent 12/15/2014 8:15:56 AM 2784 (0x0AE0) Inventory: Temp report = C:\WINDOWS\CCM\Inventory\Temp\c2ec42b6-04ab-4436-8539-73c4c01814ef.xml InventoryAgent 12/15/2014 8:15:56 AM 2784 (0x0AE0) Inventory: Starting reporting task. InventoryAgent 12/15/2014 8:15:56 AM 12860 (0x323C) Reporting: 88 report entries created. InventoryAgent 12/15/2014 8:15:57 AM 12860 (0x323C) Inventory: Reporting Task completed in 1.250 seconds InventoryAgent 12/15/2014 8:15:57 AM 12860 (0x323C) Inventory: Successfully sent report. Destination:mp:MP_HinvEndpoint, ID: {9B6353AA-DC2A-4DB7-9E8E-4392E0F05579}, Timeout: 80640 minutes MsgMode: Signed, Not Encrypted InventoryAgent 12/15/2014 8:15:57 AM 12860 (0x323C) Inventory: Cycle completed in 138.907 seconds InventoryAgent 12/15/2014 8:16:25 AM 12860 (0x323C) Inventory: Action completed. InventoryAgent 12/15/2014 8:16:25 AM 12860 (0x323C) Inventory: ************************ End of message processing. ************************ InventoryAgent 12/15/2014 8:16:25 AM 12860 (0x323C) -
Hello Windows-noob! I apologize if this is the wrong place to put this, however I'm new to this site and trying to get this resolved quickly. I'm having issues completing the installation of a SCCM client on a Windows 2008 R2 Server (It happens to be our Exchange box). Our site is up and functioning correctly - out of about 400 computers, this is the only problem I've ever had. On the client in the ClientIDManagerStartup Log, It says "Server rejected registration request: 3". On the server in the MP_RegistrationManager log, I've attached a snippet of the errors that keep repeating. I've tried resintalling, deleting the certificates, deleting the SMSCFG.INI file, and I can't seem to get it to work. I'm limited as far as what I can do to the server on-hours since it's our exchange server - for example I can't restart it anytime after 6:30 AM, so that has hindered my troubleshooting a little bit. It's the last PC I have on our entire network that needs the client, so any help will be appreciated. Thanks, opher15
-
Hello, I recently setup SCCM 2012 using the Unified installer from Microsoft. I have a simple network with 1 DC and a few servers & workstations, all within the 10.0.30.0/24 subnet. All servers are Windows 2008 R2, and workstations are a mix of WinXP, 7, and 8. I have been able to get the client to install on 4 of the machines on my network - all are servers running Windows Server 2008 R2. However, when I attempt to push the client to my remaining Windows Server 2008 R2 or Win XP, Win7, or Win8 boxesit fails. When I take a look at the C:\Windows\CCMSETUP\ccmsetup.log files the only thing I can find that is interesting is as follows: <![LOG[site version '5.00.7711.0000' is compatible. Client deployment will continue.]LOG]!><time="00:35:05.552+240" date="05-21-2012" component="ccmsetup" context="" type="1" thread="232" file="ccmsetup.cpp:289"> <![LOG[Couldn't verify 'C:\Windows\ccmsetup\Silverlight.exe' authenticode signature. Return code 0x800b0003]LOG]!><time="00:35:05.552+240" date="05-21-2012" component="ccmsetup" context="" type="3" thread="232" file="util.cpp:1270"> <![LOG[File C:\Windows\ccmsetup\Silverlight.exe size is 0.]LOG]!><time="00:35:05.552+240" date="05-21-2012" component="ccmsetup" context="" type="3" thread="232" file="util.cpp:1280"> <![LOG[A Fallback Status Point has not been specified. Message with STATEID='316' will not be sent.]LOG]!><time="00:35:05.552+240" date="05-21-2012" component="ccmsetup" context="" type="1" thread="232" file="ccmsetup.cpp:8443"> <![LOG[installFromManifest failed 0x80004005]LOG]!><time="00:35:05.552+240" date="05-21-2012" component="ccmsetup" context="" type="3" thread="232" file="ccmsetup.cpp:6259"> <![LOG[CcmSetup failed with error code 0x80004005]LOG]!><time="00:35:05.568+240" date="05-21-2012" component="ccmsetup" context="" type="1" thread="1636" file="ccmsetup.cpp:9454"> Could the fact that Silverlight.exe filesize is 0 be causing me the issues, or is this a wild goose chase? I am specifically looking at a Win7 box so I thought that BITS shouldn't be giving me an issue. I can seem to find anything relevant online when searching for "CcmSetup failed with error code 0x80004005"
-
Very new to SCCM, let alone SCCM 2012. I am assisting in a migration from SCCM 2007 to SCCM 2012, and a query was run to find a collection of machines that do not have the SCCM 2012 agent. Next an "install Client" command was run against the collection, and I can see in the ccm.log the installation of the agent running against many machines. Overall there is about 20k machines the client is being installed on. Is their a way to see the progress? When re-running the machines without agents query, it just shows up to 10k machines, so not sure how many out of the 20K have been completed already, or if there is an issue with a few hundred here or there. When looking in the console at Monitoring > Overview > Client Status > Client Activity, I can see more machines as "active" but I am not sure if it is reflecting the 2012 agents only. Appreciate any help, sorry for the basic question, but I have had trouble finding the answer in forums and via google searches.
-
First up, Thanks Anyweb, your Tuts have been fantastic, great stuff. OK we have installed SCCM2012 RC a few weeks ago and it has been running pretty well, been deploying Clients and starting to configure the various elements and have been able to get the Client installed on 102 systems out of 144. but for some unknown reason the client will not fully compete installtion. An error that I am continually seeing from one system is: Execute query exec [sp_CP_SetLastErrorCode] 2097152139, 0 Other errors, I have been able to successfully work through and testing laptops that have been turned off from the network for a while have successfully installed the client. So I am really at a miss here on working out this error and resolving it. Any idea or suggestions on how I can over come this or how to gain more info regarding this error from the ccm.log? I have read various suggestions from many websites but nothing seems to correct this issue. Thanks for any suggestions.
-
I've recently build a new SCCM 2012 server and configured client push. I've got a machine which has the cm client installed but in the collections it's showing as NO under client. There are no error messages in the clients logs. On the server logs I get: Execute query exec [sp_CP_SetLastErrorCode] 2097152366, 0 I've tried right-clicking on the machine and installing again but I get the same result. Can anyoen help? Thanks,
-
I have finally rolled out SCCM 2012 to production and most of my PC's have the client installed. However I have a laptop that fails to install the SCCM Client. I extended the Schema in my AD, I have confirmed BITS was enabled and started on the PC's services. I manually tried to force the client to install from the SMS_Site-Code\Client directory by running ccmsetup.exe. I ran it as administrator and under my domain admin account. Always fails. I checked the client's ccmsetup.log, looks like it downloads the client setup files but CcmSetup fails. If anyone can assist me I would greatly appreciate it. I need to get the SCCM Client installed on this machine ASAP. I have an upcoming Audit and the client helps me reduce a lot of overhead in pulling the reports I need for my Computers. Note: Changed Servername, client/user name for obvious reaons.<p>CcmSetup version: 5.0.7711.0000 ccmsetup 8/13/2012 2:17:48 PM 7284 (0x1C74) Running on OS (5.1.2600). Service Pack (2.0). SuiteMask = 256. Product Type = 1 ccmsetup 8/13/2012 2:17:48 PM 7284 (0x1C74) Ccmsetup command line: "C:\Users\UserID\Desktop\ccmsetup.exe" ccmsetup 8/13/2012 2:17:48 PM 7284 (0x1C74) DhcpGetOriginalSubnetMask entry point is supported. ccmsetup 8/13/2012 2:17:48 PM 7284 (0x1C74) Begin checking Alternate Network Configuration ccmsetup 8/13/2012 2:17:48 PM 7284 (0x1C74) Finished checking Alternate Network Configuration ccmsetup 8/13/2012 2:17:48 PM 7284 (0x1C74) Adapter {7A726CB2-4765-49B7-BFE9-4955826C88A5} is DHCP enabled. Checking quarantine status. ccmsetup 8/13/2012 2:17:48 PM 7284 (0x1C74) Adapter {7A83B2DB-27E6-40F9-8185-3EDDB9A501EE} is DHCP enabled. Checking quarantine status. ccmsetup 8/13/2012 2:17:48 PM 7284 (0x1C74) Current AD site of machine is Default-First-Site-Name ccmsetup 8/13/2012 2:17:48 PM 7284 (0x1C74) Attempting to query AD for assigned site code ccmsetup 8/13/2012 2:17:48 PM 7284 (0x1C74) Executing query (&(ObjectCategory=MSSMSRoamingBoundaryRange)(|(&(MSSMSRangedIPLow<=2886729797)(MSSMSRangedIPHigh>=2886729797))(&(MSSMSRangedIPLow<=2886729795)(MSSMSRangedIPHigh>=2886729795)))) ccmsetup 8/13/2012 2:17:48 PM 7284 (0x1C74) Executing query (&(ObjectCategory=mSSMSSite)(|(mSSMSRoamingBoundaries=172.16.0.0)(mSSMSRoamingBoundaries=172.16.0.0)(mSSMSRoamingBoundaries=Default-First-Site-Name))) ccmsetup 8/13/2012 2:17:48 PM 7284 (0x1C74) LSIsSiteCompatible : Verifying Site Compatibility for <CLA> ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Local Machine is joined to an AD domain ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) MP search filter is '(&(ObjectCategory=mSSMSManagementPoint)(mSSMSSiteCode=CLA))' ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Attempting to connect to AD ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) LSGetSiteVersionFromAD : Attempting to query AD for MPs for site 'CLA' ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) LSGetSiteVersionFromAD : Successfully retrieved version '5.00.7711.0000' for site 'CLA' ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) LSIsSiteCompatible : Site Version = '5.00.7711.0000' Site Capabilities = <Capabilities SchemaVersion="1.0"><Property Name="SSLState" Value="0"/></Capabilities> ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) LSIsSiteVersionCompatible : Site Version '5.00.7711.0000' is compatible. ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) LSIsSiteCompatible : Site <CLA> Version '5.00.7711.0000' is compatible. ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) LSGetAssignedSiteFromAD : Trying to Assign to the Site <CLA> ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Got site code 'CLA' from AD. ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Retrieving client operational settings from AD. ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) ClientOperationalSettings search filter is '(&(ObjectCategory=mSSMSManagementPoint)(mSSMSDefaultMP=TRUE)(mSSMSSiteCode=CLA))' ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) FromAD: MSI properties = SMSSITECODE=CLA ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) MP search filter is '(&(ObjectCategory=mSSMSManagementPoint)(mSSMSDefaultMP=TRUE)(mSSMSSiteCode=CLA))' ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Unable to open Registry key Software\Microsoft\CCM. Return Code [80070002]. Client HTTPS state is Unknown. ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) The MP name retrieved is 'SccmServer.company.lan' with version '7711' and capabilities '<Capabilities SchemaVersion="1.0"><Property Name="SSLState" Value="0"/></Capabilities>' ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) MP 'SccmServer.company.lan' is compatible ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Found MP http://SccmServer.company.lan from AD ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) SslState value: 224 ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Ccmsetup was run without any user parameters specified. Running without registering ccmsetup as a service. ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Detected sitecode 'CLA' from AD. ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) CCMHTTPPORT: 80 ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) CCMHTTPSPORT: 443 ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) CCMHTTPSSTATE: 224 ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) CCMHTTPSCERTNAME: ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) FSP: ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) CCMFIRSTCERT: 1 ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Config file: ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Retry time: 10 minute(s) ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) MSI log file: C:\Windows\ccmsetup\client.msi.log ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) MSI properties: SMSSITECODE=CLA CCMHTTPPORT="80" CCMHTTPSPORT="443" CCMHTTPSSTATE="224" CCMFIRSTCERT="1" ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Source List: ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) MPs: ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) http://SccmServer.company.lan ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) No version of the client is currently detected. ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Updated security on object C:\Windows\ccmsetup\. ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) A Fallback Status Point has not been specified. Message with STATEID='100' will not be sent. ccmsetup 8/13/2012 2:17:49 PM 7284 (0x1C74) Successfully deleted existing ccmsetup.exe ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) Downloading file C:\Users\UserID\Desktop\ccmsetup.exe ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) Downloading C:\Users\UserID\Desktop\ccmsetup.exe to C:\Windows\ccmsetup\ccmsetup.exe ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) File download 24% complete (262144 of 1052528 bytes). ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) File download 49% complete (524288 of 1052528 bytes). ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) File download 74% complete (786432 of 1052528 bytes). ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) File download 99% complete (1048576 of 1052528 bytes). ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) File download 100% complete (1052528 of 1052528 bytes). ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) Download complete. ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) Running as user "SMSAdmin" ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) Detected 193494 MB free disk space on system drive. ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) Only one MP http://SccmServer.company.lan is specified. Use it. ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) Searching for DP locations from MP(s)... ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) Current AD site of machine is Default-First-Site-Name LocationServices 8/13/2012 2:17:50 PM 7284 (0x1C74) Local Machine is joined to an AD domain LocationServices 8/13/2012 2:17:50 PM 7284 (0x1C74) Current AD forest name is company.lan, domain name is company.lan LocationServices 8/13/2012 2:17:50 PM 7284 (0x1C74) DHCP entry points already initialized. LocationServices 8/13/2012 2:17:50 PM 7284 (0x1C74) Begin checking Alternate Network Configuration LocationServices 8/13/2012 2:17:50 PM 7284 (0x1C74) Finished checking Alternate Network Configuration LocationServices 8/13/2012 2:17:50 PM 7284 (0x1C74) Adapter {7A726CB2-4765-49B7-BFE9-4955826C88A5} is DHCP enabled. Checking quarantine status. LocationServices 8/13/2012 2:17:50 PM 7284 (0x1C74) Adapter {7A83B2DB-27E6-40F9-8185-3EDDB9A501EE} is DHCP enabled. Checking quarantine status. LocationServices 8/13/2012 2:17:50 PM 7284 (0x1C74) Sending message body '<ContentLocationRequest SchemaVersion="1.00"> <AssignedSite SiteCode="CLA"/> <ClientPackage/> <ClientLocationInfo LocationType="SMSPACKAGE" DistributeOnDemand="0" UseProtected="0" AllowCaching="0" BranchDPFlags="0" AllowHTTP="1" AllowSMB="0" AllowMulticast="0" UseInternetDP="0"> <ADSite Name="Default-First-Site-Name"/> <Forest Name="company.lan"/> <Domain Name="company.lan"/> <IPAddresses> <IPAddress SubnetAddress="172.16.0.0" Address="172.16.0.69"/> <IPAddress SubnetAddress="172.16.0.0" Address="172.16.0.67"/> </IPAddresses> </ClientLocationInfo> </ContentLocationRequest> ' ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) Sending message header '<Msg SchemaVersion="1.1"><ID>{1818ABCA-412D-43A4-BABC-CE2CE70B4E8A}</ID><SourceHost>PC Name</SourceHost><TargetAddress>mp:[http]MP_LocationManager</TargetAddress><ReplyTo>direct:PC Name:LS_ReplyLocations</ReplyTo><Priority>3</Priority><Timeout>600</Timeout><ReqVersion>5931</ReqVersion><TargetHost>http://SccmServer.co.../SentTime><Body Type="ByteRange" Offset="0" Length="1248"/><Hooks><Hook3 Name="zlib-compress"/></Hooks><Payload Type="inline"/></Msg>' ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) CCM_POST 'http://SccmServer.co..._system/request' ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) Content boundary is '--aAbBcCdDv1234567890VxXyYzZ' ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) Received header '<Msg SchemaVersion="1.1"> <ID>{B052C988-D51F-428C-87A4-51C1D8B6BB42}</ID> <SourceID>GUID:DF065AA7-9E9F-4D7A-B324-645B7073598E</SourceID> <SourceHost>SccmServer</SourceHost> <TargetAddress>direct:PC Name:LS_ReplyLocations</TargetAddress> <ReplyTo>MP_LocationManager</ReplyTo> <CorrelationID>{00000000-0000-0000-0000-000000000000}</CorrelationID> <Priority>3</Priority> <Timeout>600</Timeout> <ReplyCapabilities><AllowRegistrationreset>direct:SccmServer:ClientRegistration</AllowRegistrationreset></ReplyCapabilities><TargetHost>PC Name</TargetHost><TargetEndpoint>LS_ReplyLocations</TargetEndpoint><ReplyMode>Sync</ReplyMode><Protocol>http</Protocol><SentTime>2012-08-13T19:17:50Z</SentTime><Body Type="ByteRange" Offset="0" Length="2010"/><Hooks><Hook3 Name="zlib-compress"/><Hook Name="authenticate"><Property Name="Signature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roperty><Property Name="AuthSenderMachine">SccmServer;SccmServer.company.lan;</Property><Property Name="MPSiteCode">CLA</Property></Hook></Hooks><Payload Type="inline"/></Msg>' ccmsetup 8/13/2012 2:17:50 PM 7284 (0x1C74) Received reply body '<ContentLocationReply SchemaVersion="1.00"><ContentInfo PackageFlags="16777216"/><Sites><Site><MPSite SiteCode="CLA" MasterSiteCode="CLA" SiteLocality="LOCAL" IISPreferedPort="80" IISSSLPreferedPort="443"/><LocationRecords><LocationRecord><URL Name="http://SccmServer.co...MSPKG$/CLA00001" Signature=" **UPDATE** I copied the Client folder to the local PC and ran with SMS Admin credentials, here are the 3 main errors I see in the log: Failed to download client files by BITS. Error 0x800704dd Failed to download from DP 'http://SccmServer.Company.lan/SMS_DP_SMSPKG$/CLA00001', error 0x800704dd. Fall back to MP. Failed to download client files by BITS. Error 0x800704dd
-
Hi, I am trying to do a client push install on some computers but somewhere it is failing but I cant figure out where. Here is a section of the ccm.log form the server.... ======>Begin Processing request: "2097152702", machine name: "HSN998" SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) Execute query exec [sp_IsMPAvailable] N'HSN' SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Trying the 'best-shot' account which worked for previous CCRs (index = 0x0) SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Attempting to connect to administrative share '\\HSN998\admin$' using account 'heles-school\systemadmin' SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> The 'best-shot' account has now succeeded 42 times and failed 4 times. SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Connected to administrative share on machine HSN998 using account 'heles-school\systemadmin' SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Attempting to make IPC connection to share <\\HSN998\IPC$> SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Searching for SMSClientInstall.* under '\\HSN998\admin$\' SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> System OS version string "5.1.2600" converted to 5.10 SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Service Pack version from machine "HSN998" is 3 SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Mobile client on the target machine has the same version, and 'forced' flag is turned on. SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Creating \ VerifyingCopying exsistance of destination directory \\HSN998\admin$\ccmsetup. SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Copying client files to \\HSN998\admin$\ccmsetup. SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Copying file "D:\Program Files\Microsoft Configuration Manager\bin\I386\ccmsetup.exe" to "ccmsetup.exe" SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Created service "ccmsetup" on machine "HSN998". SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Started service "ccmsetup" on machine "HSN998". SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Deleting SMS Client Install Lock File '\\HSN998\admin$\SMSClientInstall.HSN' SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) Execute query exec [sp_CP_SetLastErrorCode] 2097152702, 0 SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) ---> Completed request "2097152702", machine name "HSN998". SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) Deleted request "2097152702", machine name "HSN998" SMS_CLIENT_CONFIG_MANAGER 07/08/2012 09:46:26 5036 (0x13AC) It says it has started the ccmsetup service on the client but then has a line about an error which i dont understand. I looked at a log file found from google and a sucessfull log didnt have an error line there. The folders are on the client, c:\windows\ccmsetup and i have attached the log file from the client here Thanks for any help you can offer. ccmsetup.log -
Recently it has been added through WSUS an update for the sccm client. While it's trying to be installed we get in the logs : Have already tried all MPs. Couldn't find DP locations. ccmsetup 10/06/2012 17:15:19 4488 (0x1188) Client is not allowed to use PKI issued certificate thus it can not talk to HTTPS server. ccmsetup 10/06/2012 17:15:19 4488 (0x1188) GetHttpRequestObjects failed for verb: 'GET', url: 'https://*******/CCM_Client/ccmsetup.cab' ccmsetup 10/06/2012 17:15:19 4488 (0x1188) DownloadFileByWinHTTP failed with error 0x80004005 ccmsetup 10/06/2012 17:15:19 4488 (0x1188) Any Clues what could be the issue ? (https native client is working properly for all other updates)
